Cree una transmisión en vivo de video de alta definición desde cualquier lugar donde su producción lo lleve para sus espectadores en una variedad de servicios web utilizando el sistema VidiU X Video Streaming System de Teradek.
VidiU X le permite ingresar una señal de video HDMI desde su cámara HD y luego transmitirla en una resolución de hasta 1080p60 a Internet usando Ethernet, Wi-Fi o incluso un módem 4G / 3G opcional cuando una LAN no está disponible. También es compatible con Wi-Fi 6 y 5G, por lo que está listo para velocidades de datos súper rápidas y compatibilidad futura.
- 1x Vidiu X Encoder
- 1x Hot Shoe Adapter
- 1x Ethernet Cable
- 1x HDMI Male Type A (Full) - HDMI Male Type A (Full) 18in Cable
- 1x PSU 30W USB-C Power Adapter
- 1x Quickstart Guide
- Simple/Intuitive Set-Up: Easy to use so non-technical users can get up and running in no time
- Bonding and multi-destination streaming with Sharelink
- Video Quality: Up to 1080p60
- Compression: AVC/H.264
- Video Inputs/Outputs: HDMI
- Internet Inputs: USB for 3G/4G/5G modem support, Ethernet, and WiFi
- Cloud: Sharelink, Vidiu App
- Streaming Protocols: RTMP(S) / RTSP
- Works with any HDMI video source & has Looping HDMI output
- Dual band WiFi (802.11ax | WiFi 6)
- Gigabit Ethernet
- Full size SD card for recording
- Line / Mic input (3.5mm)
- Network bonding, Sharelink compatible for remote configuration & multi-platform streaming which is especially useful for VidiU Pro since Sharelink supports RTMPS for Facebook
- Bonding gives you reliable streaming from anywhere
- Super fast boot up time (under 10 seconds)
- Expands capabilities of Vidiu X and Go encoders
- Modern components: WiFi 6, USB-C power
- Quick config from OLED screen or VidiU app
- VidiU app allows you to overlay simple bugs and scoreboards
3. Specifications
Wireless
- Frequency Range: US: 2.4 - 5 GHz
- Wi-Fi: 2.4/5 GHz Wi-Fi 5 (802.11ac)
Interfaces
- Video Connectors:
1x HDMI Input
1x HDMI Output - Audio Connectors:
1x 1/8"/3.5mm TRS Analog Input
Other I/O: 1x RJ45 10/100/1000 Ethernet Input/Output - Embedded Audio: HDMI
IP Encoding
IP Video: H.264: 480 x 270 to 1920 x 1080 at 23.98p, 24p, 25p, 29.97p, 30p, 50i, 50p, 59.94i, 59.94p, 60p (0.25 to 12.00 Mb/s)
IP Audio: AAC-LC: (48.00 to 256.00 Kb/s)
Transport Protocols: TCP/IP, RTMP, RTMPS, RTSP, UDP, DHCP, IGMP, SSL, HTTP
Simultaneous Streams: 7 Streams
Display
Panel Type: OLED
Power
Power Connector: 1x USB Type-C Input
Power Consumption: Device: (7W)
Device: (6W)
Device: (4.5W)
Power Supply: 5 to 15 VDC
General
- Mounting:
1x 1/4"-20 Female
2x M3 Female - Memory Card Slot: 1x microSDXC
- Materials: ABS, Aluminum
- Dimensions: 4.1" x 3" x 1.1" (105mm x 75mm x 28mm)
- Weight: .06lbs (160g)
